Home > Products > automatic car wash machine >Bus/truck wash equipment(CB-720)

Bus/truck wash equipment(CB-720)

Description:

With  2 long brushes, total 2 nylon brushes.


Features:

1.With  2 long brushes, total 2 nylon brushes.

2.With pre-wash, shampoos, brushes wash, final rinse washing.

3.Bus front, rear, both sides and chassis to wash.

4.PLC control systems&Touch screen pannel.

5. Trafic light on the machine to indicate the machine to readiness.

6.Proximity swith and photo sensors for activation of washing bus.


Equipment Parameter

Model

CB-720

(Reciprocating)

Machine dimension

2949x5114x7300mm

Assembling range

21000x6580mm

Available size for car

14000x2600x4200mm

Main voltage

380v 3phase 50HZ

Total power

8.25kw

Water supply

DN25mm water flow rate≥120L/min

Air pressure

0.75-0.9MPa Air flow rate≥0.6m³/min

Shampoo consumption

25-30ml/car

Washing time

4’/car

Car wash capacity

12-15cars/hour

Top brush

/

Big side brush

2 set


Equipment Advantages

1. Can identify the car model with photoelectric and approaching sensors.
2. Hot-dip galvanized frame can keep the whole machine stable and long life use.
3. PLC electronic control panels system can easy to operate and maintain.
4. The dovetail foam brush makes the car washing more quiet and clean.
5. High quality control systems, motors and pumps from Japan can keep the car wash running with great performance in any conditions.
6. The high sensor on the top brush can keep the bus from damage.
7. The motor with IP67 make the machine work well in the water condition.
8. Fully automatic wash rolls over the rails and easy to install, operate use and maintain.
9. With on-site installation and operate training for free and long time quality guarantee to whole car wash.
