Home > Products > automatic car wash machine >Tunnel car wash machine(CC-670)

Tunnel car wash machine(CC-670)

Description:

Risense automatic tunnel car wash system is equipped with such advanced technologies as synchronous tire sensor to guide the car into the car wash machine and can shorten the space, the Japanese second-generation super-soft flannelette brush and foam brush as well as top profiling air-dry.


Features:

1)  High pressure water pre-washing

2)  Shampoo(foams) sprinkling and wax washing systems.

3)  Three blowers dry the car body completely and precisely.

4)  PLC control system & humanized operate pannel.

5)  Intelligent avoidance system to wash all kinds of car types.

6)  Electroplated conveyor equipped with the corrector device.

7) Hop-dip galvanized steel frame keep the whole machine antirust.


Equipment Parameter

Model

CC-670

Machine dimension

8340x3800x3400mm

Conveyor length

9960mm

Assembling range

9960x3800mm

Available size for car

5300x2150x2270m

Available car to wash

car/jeep/coach within 10 seats

Main voltage

380v 3phase 50HZ/60HZ

Total power

34.02kw

Water supply

DN25mm water flow rate≥200L/min

Air pressure

0.75-0.9MPa Air flow rate≥0.6m³/min

Water/electricity consumption

150L/car  0.66kw/car

Shampoo consumption

8ml/car

Water Wax consumption

12ml/car

Washing time

1’12’’/car

Car wash capacity

50-60cars/hour

Top brush

1 set

Big side brush

4 set

Small side brush

2 set

Wheel brush

/

Dry brush

/


Equipment Advantages

1. High pressure water-washing and chassis sprinkling.

2. Shampoo(foams) sprinkling and wax washing system.

3. 7 brushes with foam material and lifelong warranty.

4. Blowing system dry the car body completely and precisely.

5. PLC control system & humanized operate pannel.

6. Intelligent avoidance system to wash all kinds of car types.

7. Main technology and machine design from Japan.

8. Electroplated conveyor equipped with the tire corrector device.

9. Hop-dip galvanized steel frame keep the whole machine antirust.

10. Motors, electrical apparatus, pumps are all imported from abroad.

11. No less than 15 years'using time.

12. With one-site installation and operate training for free.


Equipment Parameter
High efficient drying systemPLC control system made in JapanLiquid automatic mixing and spraying systemJapan TSUBAKI frequency conversion motor(IP67)
Waxing spraying systemClothing/Fourth generation foam brushHot-dip galvanized steel frame

Anti-fire thin film
